PERFORMANCE

• Platform Height (Elevated)
• Platform Capacity
• Capacity on Platform Extension
• Number of Occupants
• Lift / Lower Time (No Load)
• Lift / Lower Time (Rated Load)
• Maximum Drive Height
• Weight*
• Max. Ground Bearing Pressure
• Drive Speed (Lowered)
• Drive Speed (Raised)
• Gradeability
• Max Tilt Rating (Side-to-Side)
• Max Tilt Rating (Fore and Aft)
• Turning Radius (Inside)
• Turning Radius (Outside)
  *Certain options or country standards increase weight

INDOOR

• 13-ft / 3.8-m
• 500-lb / 227-kg
• 250-lb / 115-kg
• 2
• 17/17 seconds
• 20/16 seconds
• Fully Elevated
• 1,984-lb / 900-kg
• 119 psi / 8.3 kg/cm²
• 2.4 mph / 3.8 km/h
• 0.5 mph / 0.8 km/h
• 25%
• 1.75 Degrees
• 3 Degrees
• Zero
• 55-in / 1.4-m

OUTDOOR

• 13-ft / 3.8-m
• 500-lb / 227-kg
• 250-lb / 115-kg
• 2
• 17/17 seconds
• 20/16 seconds
• Fully Elevated
• 1,984-lb / 900-kg
• 119 psi / 8.3 kg/cm²
• 2.4 mph / 3.8 km/h
• 0.5 mph / 0.8 km/h
• 25%
• 1.75 Degrees
• 3 Degrees
• Zero
• 55-in / 1.4-m
